Software Requirements
CurrentWare is supported on local or cloud based desktop computers, virtual machines (VMs) and servers with the following operating system specifications:
| CurrentWare Server | CurrentWare Clients |
|---|---|
|
|
- All CurrentWare components are compatible with Remote Desktop Services (RDS), Terminal Servers (TS), and Windows-based virtual desktop infrastructure (VDI).
- Warning: It is not recommended to install CurrentWare on the same server as any Domain Controller, Exchange or WSUS (Windows Server Update Services) IIS pages or application pools.
- ★Please reach out to our sales team for trial information. More AccessPatrol for Windows XP information here.
Server Hardware Requirements
All components of CurrentWare are supported on desktop computers and server computers with the following specifications:
| Number of clients★ | Recommended Hardware Specifications for Server Running CurrentWare Suite |
| Up to 100 Clients | CPU: 4 Cores RAM: 8 GB Disk Space: 100+ GB of free space for SQL database, local backups, and screenshots. SQL Database: SQL Express = ~ 2-3 months of data retention |
| 100-500 | CPU: 4 – 8 Cores RAM: 16 GB Disk Space: 150+ GB of free space for SQL database, local backups, and screenshots. SQL Database: SQL Express = ~ 1-2 months of data retention. SQL Standard / Enterprise Recommended |
| 500-1000 | CPU: 8 – 16 Cores RAM: 16 – 24 GB Disk Space: 200+ GB of free space for SQL database, local backups, and screenshots. SQL Database: SQL Express = ~ 1 month of data retention. SQL Standard / Enterprise Recommended |
| 1000+ | CPU: 16 Cores RAM: 24+ GB Disk Space: 200+ GB of free space for SQL database, local backups, and screenshots. SQL Database: SQL Express is not recommended. SQL Standard / Enterprise Recommended |
★The specifications apply to a standard user engaged in routine office tasks. If you are not running the entire CurrentWare suite your requirements may vary.
SQL Server
CurrentWare runs on SQL database and supports the following versions:
- SQL Server 2022
- SQL Server 2019
- SQL Server 2017
- SQL Server 2016
- SQL Server 2014
- SQL Server 2012
SQL Server Express: CurrentWare also supports SQL Server Express, which is the free version of SQL Server. It comes prepackaged with the CurrentWare Server installer. There is a 10 GB limit for SQL Express. To maintain your database to stay under the limit see this article: Database Maintenance
CurrentWare Client Footprint
The CurrentWare Client can be installed on your computers remotely and silently. It is lightweight and requires minimal system requirements to run. It runs discreetly and its impact on performance is minimal.
The CurrentWare Client tracks computer activities and stores the data locally. The data is uploaded to the CurrentWare server every few minutes.
Key Metrics:
- Total installed file size of the CurrentWare Client is less than 15 MB.
- Total CPU memory usage is between 12-15 MB.
- Total local data storage is less than 1 MB.
- Total daily average data collected from the CurrentWare Client is less than 1 MB.
NOTE: To install the CurrentWare Client the PC must have a local C:\ Drive.
Network Requirements
All of the following network ports must be opened on the firewall of the machine hosting the CurrentWare server. If you are connecting your client computers from outside your network, you will need to configure port forwarding on your router.
Based on your solution(s) installed you may have different port requirements. See the proper tab below for your ports needed.
| Ports and Protocol | What the ports handle |
| 8989-8992, 8995-8999 TCP/UDP | Client+Console connection and data upload ports |
| 8988 TCP/UDP | Live Capture feature – OPTIONAL – For BrowseReporter live capture feature |
| 8993 TCP/UDP | Screenshots Upload – For BrowseReporter screen capture |
| 1433-1434 TCP/UDP | For SQL Database only – OPTIONAL – If you find the 899x range ports are not providing dataflow |
